Hot tap water boiler electric STIEBEL ELTRON

Add to selection
General information
Ordercode YESSS
6027-9936
Product code
073047
EAN code
4017210730470
Product group
Hot tap water boiler electric
Brand
STIEBEL ELTRON
Product specifications
Material boiler tank
Steel
Material casing
Steel
Tank volume
30 l
Nominal power
6 kW
Connection voltage
230 - 400 V
Frequency
50 Hz
Design form
Hanging
Plinth boiler
No
With off-peak electricity circuit
No
Duo model
No
Suitable for boiling water
No
Heat-up time from 10 °C to 65 °C
18 min
Tap capacity at 60 °C, continuous
18 l/min
Wall set-up
Yes
Horizontal positioning
No
Vertical positioning
Yes
With temperature indication
No
With temperature limit
Yes
With circulation connection
No
Max. allowable operating pressure
6 bar
With tap/mixer
No
With pressure reducing valve
No
With thermometer
No
With cleaning opening
No
Protective anode
Yes
Height
770 mm
Width
410 mm
Depth
420 mm
Cold tap water connection
External thread
Nominal diameter cold tap water
1/2 inch (15)
Outer pipe diameter cold tap water
21.5 mm
Hot tap water connection
External thread
Nominal diameter hot tap water
1/2 inch (15)
Outer pipe diameter hot tap water
21.5 mm
Degree of protection (IP)
IP25
Water heating energy efficiency (Nwh)
36 %
Capacity profile
S
Energy efficiency class
B
more specifications
